hehe, already noticed the if/else code for red-blinking warning when battery level falls below 20% ...
Just tried the set of laptop conkies on my Devuan fluxbox install. Each and every one is working correctly, needed some personal adjustments for my system.
is set to false (or missing), but that is probably because I have compton (or picom) compositor running. Most DE's will have some compositor running in the background.
setting running, or at least not at the same time. I've set the argb_value to "0" and let the lua script take over this task.
Actually, I'm using Mr.Peachy's updated script 'transbg.lua', which allows for setting the corner-radius / color / opacity pct levels per individual conky config, e.g:
Code: Select all
--[[Background originally by londonali1010 (2009)
ability to set any size for background mrpeachy 2011
ability to set variables for bg in conkyrc dk75
the change is that if you set width and/or height to 0
then it assumes the width and/or height of the conky window
so:
Above and After TEXT (requires a composite manager or it blinks!)
lua_load ~/wea_conky/draw_bg.lua
TEXT
${lua conky_draw_bg 10 0 0 0 0 0x000000 0.2}
OR Both above TEXT (no composite manager required - no blinking!)
lua_load ~/wea_conky/draw_bg.lua
lua_draw_hook_pre draw_bg 10 0 0 0 0 0x000000 0.2
TEXT
Note
${lua conky_draw_bg 20 0 0 0 0 0x000000 0.2}
See below: 1 2 3 4 5 6 7
${lua conky_draw_bg corner_radius x_position y_position width height color alpha}
covers the whole window and will change if you change the minimum_size setting
1 = 20 corner_radius
2 = 0 x_position l|r
3 = 0 y_position u|d
4 = 0 width
5 = 0 height
6 = 0x000000 color
7 = 0.4 alpha
######### calendar function ##################################################
then to use it, you activate the calendar function BELOW TEXT like this
${lua luacal {settings}}
#${lua luacal {x=,y=,tf="",tfs=,tc=,ta=,bf="",bfs=,bc=,ba=,hf="",hfs=,hc=,ha=,sp="",gh=,gt=,gv=,sd=}}
# x=x position top left
# y=y position top left
# tf=title font, eg "mono" must be in quotes
# tfs=title font size
# tc=title color
# ta=title alpha
# bf=body font, eg "mono" must be in quotes
# bfs=body font size
# bc=body color
# ba=body alpha
# hf=highlight font, eg "mono" must be in quotes
# hfs=highlight font size
# hc=highlight color
# ha=highlight alpha
# sp=spacer, eg " " or sp="0"... 0,1 or 2 spaces can help with positioning of non-monospaced fonts
# gt=gap from title to body
# gh=gap horizontal between columns
# gv=gap vertical between rows
# sd=start day, 0=Sun, 1=Mon
# hstyle = heading style, 0=just days, 1=date insert
# tdf=title date font, eg "mono" must be in quotes
# tdfs=title date font size
# tdc=title date color
# tda=title date alpha
# test line
-- ${lua luacal {x=40,y=40,tf="Monofur",tfs=24,tc=0xFFDEAD,ta=1,bf="Monofur",bfs=24,bc=0xFFDEAD,ba=1,hf="Monofur",hfs=24,hc=0x00BFFF,ha=1,sp=" ",gh=40,gt=25,gv=20,sd=0,hstyle=1,tdf="Monofur",tdfs=24,tdc=0x00BFFF,tda=1}}
]]
require 'cairo'
local cs, cr = nil
function rgb_to_r_g_b(colour,alpha)
return ((colour / 0x10000) % 0x100) / 255., ((colour / 0x100) % 0x100) / 255., (colour % 0x100) / 255., alpha
end
function conky_draw_bg(r,x,y,w,h,color,alpha)
if conky_window == nil then return end
if cs == nil then cairo_surface_destroy(cs) end
if cr == nil then cairo_destroy(cr) end
local cs = cairo_xlib_surface_create(conky_window.display, conky_window.drawable, conky_window.visual, conky_window.width, conky_window.height)
local cr = cairo_create(cs)
w=w
h=h
if w=="0" then w=tonumber(conky_window.width) end
if h=="0" then h=tonumber(conky_window.height) end
cairo_set_source_rgba (cr,rgb_to_r_g_b(color,alpha))
--top left mid circle
local xtl=x+r
local ytl=y+r
--top right mid circle
local xtr=(x+r)+((w)-(2*r))
local ytr=y+r
--bottom right mid circle
local xbr=(x+r)+((w)-(2*r))
local ybr=(y+r)+((h)-(2*r))
--bottom right mid circle
local xbl=(x+r)
local ybl=(y+r)+((h)-(2*r))
-----------------------------
cairo_move_to (cr,xtl,ytl-r)
cairo_line_to (cr,xtr,ytr-r)
cairo_arc(cr,xtr,ytr,r,((2*math.pi/4)*3),((2*math.pi/4)*4))
cairo_line_to (cr,xbr+r,ybr)
cairo_arc(cr,xbr,ybr,r,((2*math.pi/4)*4),((2*math.pi/4)*1))
cairo_line_to (cr,xbl,ybl+r)
cairo_arc(cr,xbl,ybl,r,((2*math.pi/4)*1),((2*math.pi/4)*2))
cairo_line_to (cr,xtl-r,ytl)
cairo_arc(cr,xtl,ytl,r,((2*math.pi/4)*2),((2*math.pi/4)*3))
cairo_close_path(cr)
cairo_fill (cr)
------------------------------------------------------------
cairo_surface_destroy(cs)
cairo_destroy(cr)
return ""
end
-- ###### calendar function ##################################################
function conky_luacal(caltab) -- {x=,y=,tf="",tfs=,tc=,ta=,bf="",bfs=,bc=,ba=,hf="",hfs=,hc=,ha=,sp="",gt=,gh=,gv=,sd=,hstyle=,tdf=,tdfs=,tdc=,tda=}
if conky_window == nil then return end
local cs = cairo_xlib_surface_create(conky_window.display, conky_window.drawable, conky_window.visual, conky_window.width, conky_window.height)
local cr = cairo_create(cs)
--############################################################################
if caltab.x==nil then
caltab=loadstring("return" .. caltab)()
end
local cal_x=caltab.x
local cal_y=caltab.y
local tfont=caltab.tf or "mono"
local tfontsize=caltab.tfs or 12
local tc=caltab.tc or 0xffffff
local ta=caltab.ta or 1
local bfont=caltab.bf or "mono"
local bfontsize=caltab.bfs or 12
local bc=caltab.bc or 0xffffff
local ba=caltab.ba or 1
local hfont=caltab.hf or "mono"
local hfontsize=caltab.hfs or 12
local hc=caltab.hc or 0xff0000
local ha=caltab.ha or 1
local spacer=caltab.sp or " "
local gaph=caltab.gh or 20
local gapt=caltab.gt or 15
local gapl=caltab.gv or 15
local sday=caltab.sd or 0
local hstyle=caltab.hstyle or 0
--convert colors
--local font=string.gsub(font,"_"," ")
local tred,tgreen,tblue,talpha=rgb_to_r_g_b(tc,ta)
--main body text color
local bred,bgreen,bblue,balpha=rgb_to_r_g_b(bc,ba)
--highlight text color
local hred,hgreen,hblue,halpha=rgb_to_r_g_b(hc,ha)
--############################################################################
--calendar calcs
local year=os.date("%G")
local today=tonumber(os.date("%d"))
local t1 = os.time( { year=year,month=03,day=01,hour=00,min=0,sec=0} );
local t2 = os.time( { year=year,month=02,day=01,hour=00,min=0,sec=0} );
local feb=(os.difftime(t1,t2))/(24*60*60)
local monthdays={ 31, feb, 31, 30, 31, 30, 31, 31, 30, 31, 30, 31 }
local day=tonumber(os.date("%w"))+1-sday
local day_num = today
local remainder=day_num % 7
local start_day=day-(day_num % 7)
if start_day<0 then start_day=7+start_day end
local month=os.date("%m")
local mdays=monthdays[tonumber(month)]
local x=mdays+start_day
local dnum={}
local dnumh={}
if mdays+start_day<36 then
dlen=35
plen=29
else
dlen=42
plen=36
end
for i=1,dlen do
if i<=start_day then
dnum[i]=" "
else
dn=i-start_day
if dn=="nil" then dn=0 end
if dn<=9 then dn=(spacer .. dn) end
if i>x then dn="" end
dnum[i]=dn
dnumh[i]=dn
if dn==(spacer .. today) or dn==today then
dnum[i]=""
end
if dn==(spacer .. today) or dn==today then
dnumh[i]=dn
place=i
else dnumh[i]=" "
end
end
end--for
cairo_select_font_face (cr, tfont, CAIRO_FONT_SLANT_NORMAL, CAIRO_FONT_WEIGHT_NORMAL);
cairo_set_font_size (cr, tfontsize);
cairo_set_source_rgba (cr,tred,tgreen,tblue,talpha)
local extents=cairo_text_extents_t:create()
tolua.takeownership(extents)
if hstyle==0 then
if tonumber(sday)==0 then
dys={"SU","MO","TU","WE","TH","FR","SA"}
else
dys={"MO","TU","WE","TH","FR","SA","SU"}
end
--draw calendar titles
elseif hstyle==1 then
if tonumber(sday)==0 then
dys={"SU","MO"," "," "," ","FR","SA"}
cairo_text_extents(cr,"MO",extents)
local s=extents.x_advance+gaph
local f=gaph*5
local tdfont=caltab.tdf or "mono"
local tdfontsize=caltab.tdfs or 12
local tdc=caltab.tdc or 0xffffff
local tda=caltab.tda or 1
cairo_select_font_face (cr, tdfont, CAIRO_FONT_SLANT_NORMAL, CAIRO_FONT_WEIGHT_NORMAL);
cairo_set_font_size (cr, tdfontsize);
local tdred,tdgreen,tdblue,tdalpha=rgb_to_r_g_b(tdc,tda)
cairo_set_source_rgba (cr,tdred,tdgreen,tdblue,tdalpha)
local insert=os.date("%b %y")
cairo_text_extents(cr,insert,extents)
local w=extents.x_advance
cairo_move_to (cr, cal_x+((s+f)/2)-(w/2), cal_y)
cairo_show_text (cr,insert)
cairo_stroke (cr)
else
dys={"MO","TU"," "," "," ","SA","SU"}
cairo_text_extents(cr,"TU",extents)
local s=extents.x_advance+gaph
local f=gaph*5
local tdfont=caltab.tdf or "mono"
local tdfontsize=caltab.tdfs or 12
local tdc=caltab.tdc or 0xffffff
local tda=caltab.tda or 1
cairo_select_font_face (cr, tdfont, CAIRO_FONT_SLANT_NORMAL, CAIRO_FONT_WEIGHT_NORMAL);
cairo_set_font_size (cr, tdfontsize);
local tdred,tdgreen,tdblue,tdalpha=rgb_to_r_g_b(tdc,tda)
cairo_set_source_rgba (cr,tdred,tdgreen,tdblue,tdalpha)
local insert=os.date("%b %y")
cairo_text_extents(cr,insert,extents)
local w=extents.x_advance
cairo_move_to (cr, cal_x+((s+f)/2)-(w/2), cal_y)
cairo_show_text (cr,insert)
cairo_stroke (cr)
end
end
--draw calendar titles
for i=1,7 do
cairo_select_font_face (cr, tfont, CAIRO_FONT_SLANT_NORMAL, CAIRO_FONT_WEIGHT_NORMAL);
cairo_set_font_size (cr, tfontsize);
cairo_set_source_rgba (cr,tred,tgreen,tblue,talpha)
cairo_move_to (cr, cal_x+(gaph*(i-1)), cal_y)
cairo_show_text (cr, dys[i])
cairo_stroke (cr)
end
--draw calendar body
cairo_select_font_face (cr, bfont, CAIRO_FONT_SLANT_NORMAL, CAIRO_FONT_WEIGHT_NORMAL);
cairo_set_font_size (cr, bfontsize);
cairo_set_source_rgba (cr,bred,bgreen,bblue,balpha)
for i=1,plen,7 do
local fn=i
for i=fn,fn+6 do
cairo_move_to (cr, cal_x+(gaph*(i-fn)),cal_y+gapt+(gapl*((fn-1)/7)))
cairo_show_text (cr, dnum[i])
cairo_stroke (cr)
end
end
--highlight
cairo_select_font_face (cr, hfont, CAIRO_FONT_SLANT_NORMAL, CAIRO_FONT_WEIGHT_NORMAL);
cairo_set_font_size (cr, hfontsize);
cairo_set_source_rgba (cr,hred,hgreen,hblue,halpha)
for i=1,plen,7 do
local fn=i
for i=fn,fn+6 do
cairo_move_to (cr, cal_x+(gaph*(i-fn)),cal_y+gapt+(gapl*((fn-1)/7)))
cairo_show_text (cr, dnumh[i])
cairo_stroke (cr)
end
end
--############################################################################
caltab=nil
dlen=nil
plen=nil
cairo_destroy(cr)
cairo_surface_destroy(cs)
cr=nil
return ""
end
-- end main function #########################################################
Since these are square the matching square corners don't offend me too much..
